T-Shape Roof Console | 79 Dual Cab & 76 Wagon

$1,745.00
Made to Order · 3 Weeks
Secure payments

We're closed from 23 December to 11 January. Orders will be processed when we return, so please allow an extra 12 business days on top of the lead time above.

Color: DeluxeTrim Roof ( Grey )
Model Variant: 2009-2022 Pre AEB
Rocker Switch Panel: No Rocker Switch Panel
Build your roof console Tick extras to preview the layout.
T-shape roof console layout sketch preaeb-6-nr
Not sure what the extras are? See below
Radios that suit this roof console

Add a GME XRS-335C, fitted into your console.

Running total: $1,745.00
Australian made since 1975
Secure checkout

T-Shape Roof Console | Toyota LandCruiser 79 Series Dual Cab & 76 Series Wagon

Version 2 of our T-Shape Roof Console  now with an integrated 6-rocker switch panel as standard. Designed and handmade in Australia for the Toyota LandCruiser 79 Series Dual Cab (all models) and 76 Series Wagon (2009+). VDJ and 1GD, Auto and Manual variants. A refinement of a product we've been building for over 30 years.

FITMENT

  • Toyota 79 Series Dual Cab : 2009 to 2026 (all models including Facelift)
  • Toyota 76 Series Stationwagon : 2009 to 2026 (AEB, pre-AEB & Facelift)

Note: Vehicles fitted with roof insulation or sound-deadening material thicker than 3mm may experience reduced clearance.

Note: 2023+ Facelift models include an integrated factory microphone provision within the rocker panel.

FEATURES

  • Six overhead  or four storage openings with internal lining, netting and dividers
  • Directional LED map lights with individual switches
  • Optional driver-side UHF radio provision on angled fascia
  • Premium sewn vinyl with French seam upholstery
  • Uses existing factory mounting points: no drilling required
  • Designed to look and feel factory fitted

INTEGRATED ACCESSORY MOUNTING

  • Front internal: suits GME XRS-335C radio internal mount
  • Front near map lights: Quad Lock mount for action camera
  • Rear: Quad Lock mount for phone or tablet (facing rear passengers)

SPECIFICATIONS

  • Construction: Exterior-grade, marine-bonded plywood
  • Upholstery: Premium sewn vinyl, French seam finish
  • Switch panel: 6-rocker/Carling with blanking plates
  • Make: Toyota
  • Suits: 79 Series Dual Cab, 76 Series Stationwagon
  • Years: 2009–2026
  • Manufactured by: DOTI Automotive, Australia

INSTALLATION Direct bolt-in using existing factory mounting points. No drilling or modification required.


Points of Interest

  • Six or four storage openings
    Six or four storage openingsSix overhead openings are standard, or choose four with a 45° angled fascia with internal lining, netting and dividers.
  • No drilling required
    No drilling requiredFits using the rear-view mirror, grab handle captive nuts, and interior light screw holes. Fitting kit and instructions included.
  • Marine plywood and steelExterior-grade, marine-bonded plywood construction with steel no plastic. Upholstered in your choice of vinyl with French seam finish.
  • UHF provision cut to suit
    UHF provision cut to suitMade to order: provide your UHF model and we’ll cut a driver-side provision to suit (handpiece mounts recommended when needed).
  • 6 rocker switch panel
    6 rocker switch panelOptional on Pre-AEB and AEB. Facelift includes the 6-rocker panel with integrated factory microphone provision.
  • LED map lights
    LED map lightsDirectional LED map lights with individual switches. Facelift models retain the factory rear light provision with a Narva LED globe.
  • Handmade in Australia
    Handmade in AustraliaDesigned and handmade by DOTI Automotive for LandCruiser 79 Series Dual Cab and 76 Series Wagon (2009–2026, incl. Facelift).

Specifications

Construction Marine plywood and steel , no plastic
Upholstery Premium sewn vinyl, French seam finish (choice of vinyl)
Storage openings Six standard, or four with 45° angled fascia; lined with netting and dividers
Switch panel 6-rocker / Carling with blanking plates , optional on Pre-AEB/AEB; Facelift includes panel with microphone provision
Lighting Pre-AEB/AEB: Narva LED map light with 3-way switch. Facelift: factory rear light provision + Narva LED globe
UHF Provision cut to suit your radio (made to order)
Fitment Toyota 79 Series Dual Cab & 76 Series Stationwagon, 2009–2026 (Pre-AEB, AEB & Facelift)
Installation No drilling , uses rear-view mirror, grab handle captive nuts and interior light screw holes; fitting kit and instructions included
Lead time Made to order
Manufactured by DOTI Automotive, Australia

Console extras explained

What each extra in the builder above adds to your roof console.

  • T-shape roof console with 4 storage openings fitted in a 79 Series
    T-shape roof console with standard 6 storage openings fitted in a 79 Series
    Standard: 6 storage openings

    4 Storage Openings Only

    −$180.00

    Six openings are standard. Choose four with a 45° angled fascia.

  • External charging socket and switch on the side of a T-shape roof console

    Charging sockets

    +$60.00

    Externally mounted at the rear — 12V + dual USB-A/C.

  • Layout sketch of the T-shape roof console showing the position of the Internal Charging sockets Layout sketch

    Internal Charging sockets

    +$60.00

    Inside the storage compartment above the sun visors.

  • Rear LED map lights and switches on a T-shape roof console

    Rear LED Map Lights

    +$105.00

    Extra map lights at the rear of the console.

  • Quad Lock mount on the front of a T-shape roof console holding an action camera

    Front Quad Lock Mounting Hardware

    +$40.00

    Hardware only — near the front map lights.

    What’s included
    • 1 x Quad Lock 360 Arm – Dual Pivot
    • 1 x Quad Lock 360 Base – Flat Rectangle (2 hole)
  • Phone on Quad Lock mount fitted to the rear of a T-shape roof console

    Rear Quad Lock Mounting Hardware

    +$40.00

    Hardware only — rear passenger-facing mount.

    What’s included
    • 1 x Quad Lock 360 Arm – Dual Pivot
    • 1 x Quad Lock 360 Base – Flat Rectangle (2 hole)
Know what accessories you want? Add now

Frequently asked questions

Answers specific to the T-Shape roof console.

1. Will the T-Shape Roof Console fit my vehicle?

This listing suits the Toyota LandCruiser 79 Series Dual Cab and 76 Series Wagon, 2009 onwards, including AEB models and the 2023/24+ facelift (VDJ and 1GD, auto and manual). It bolts into the factory mounting points, so no drilling is needed.

When you order, select your model variant: pre-AEB, AEB or facelift. 2023 is a crossover year for the 70 Series facelift, so if you have a 2023 model, please check the identifier photos on this page to confirm which version you have.

Other vehicles: we don't currently make a T-Shape outside the 70 Series range. If you'd like one for your vehicle, get in touch and we'll add you to our waitlist. We may develop new models when there's enough demand.

2. Does the console come with 6 or 4 storage openings?

The console comes with 6 storage openings as standard, each with elasticised netting, internal carpet lining and dividers. If you'd prefer 4 storage openings, simply select the 4 storage option and $180 will be removed from the cost of your console.

3. Can I change the layout or add custom cut-outs?

Yes, in many cases. Every T-Shape is handmade to order in our Sydney workshop, so we can often tailor it to your setup. Popular requests include choosing your UHF provision (Q4), keeping your factory interior light (Q8), and adding charging sockets or a gauge (Q11).

There are a few limits. We don't offer storage openings on the angled side facias, a downward-pointing angled facia, or a different style of rear-facing light. Some displays, such as the REDARC RedVision, don't fit within the console's dimensions (Q11).

For anything outside our standard options, a $120 custom fee applies. Please use the Send a custom enquiry button and include:

  • your name
  • your vehicle details (year, model, and pre-AEB, AEB or facelift)
  • the items, accessories or customisation you'd like to fit, with links to those items

We'll confirm what's possible before you order.

4. Can I fit a UHF radio in the console?

Yes. Most customers do. Here are your options:

  • UHF provision on the driver's side angled facia: we cut it to suit your radio, so please tell us the exact brand and model when you order (e.g. GME TX4500S or other DIN-style units).
  • Compact remote-head GME radios (e.g. XRS-335C, XRS-370C): the main unit mounts neatly inside the console, so no separate provision is needed. Simply select the GME XRS-335C option on this listing. A magnetic mic mount can be fitted to the vinyl for easy access.
  • Less common radios: send us the model and dimensions and we'll confirm whether it fits.
  • No UHF: just let us know and we'll leave the provision off.

We're an authorised GME distributor, so we can also supply your radio with the console. For remote-head radios, we recommend internal brackets and wiring the power through a quick-connect plug. This makes future removal easy.

5. Do you ship Australia-wide and internationally?

Yes. We ship Australia-wide. The console ships in a large box (approx. 135 x 100 x 20 cm), so freight is calculated on your delivery address and shown at checkout. Delivery to a business address is usually cheaper than to a residential address, and remote and WA deliveries cost more because of the box size. You're also welcome to collect from our Kingsgrove (Sydney) warehouse.

International orders are available on request. Roof linings vary between markets, so we'll ask for photos of your front roof lining, factory interior light, sun visors and rear-view mirror area to confirm compatibility before we quote. A $120 international fee applies. If you'd prefer to arrange your own freight, we'll quote packaging and handling for you instead.

6. How long will it take?

Each T-Shape is made to order, so lead times vary through the year. Please check our current lead times page for the latest estimate. We sometimes have a ready-made unit in stock, so it's worth asking.

7. What's different on the 2023/24+ facelift version?

Toyota changed the roof area on the facelift models, so the facelift T-Shape has two key differences:

  • Factory Bluetooth microphone: the factory microphone is housed in one position of the rocker switch panel so you can keep using it. That's why the facelift version always comes with the switch panel and has 5 switch positions (Q9).
  • Interior light: instead of the Narva 87509 light, the console has a provision to refit your factory interior light, upgraded with Narva LED globes. This keeps the factory door and dimming function working properly.
8. What lighting does it come with, and can I keep my factory light?

Every T-Shape includes directional aluminium LED map lights at the front, each with its own switch.

  • Pre-facelift (2009–2023) models: the rear interior light is upgraded to a Narva 87509 LED light with a 3-way On/Off/Door switch. Prefer to keep your factory interior light? We can make the console to suit it instead, or leave the rear light off entirely.
  • 2023/24+ facelift models: your factory interior light is refitted with Narva LED globes (see Q7).
  • Rear LED map lights: an optional pair of rear-facing LED map lights, each with an on/off switch, for your rear passengers.

Need a replacement map light or interior light for an older T-Shape? We stock replacements. Styles have changed over the years, so send us a photo of your current light so we can match it.

9. How many switches does the rocker switch panel take?

The rocker switch panel has 6 switch positions and suits Carling-style rocker switches. On facelift models it has 5 switch positions, because the 6th position houses the factory microphone. Unused positions come with blanking plates. The switches themselves aren't included, and we recommend having them wired by a qualified auto electrician.

On pre-facelift models, you can also choose the console without the rocker switch panel. Apart from the panel, both options are the same.

10. What colours are available?

The T-Shape is upholstered in hard-wearing automotive vinyl with French seams. Choose from:

  • DeluxeTrim Roof (light grey): our standard. It's the closest match to the factory roof lining and sun visors.
  • DeluxeTrim Black Vinyl.

Custom colour or stitching? Want a black console with Sandy Taupe stitching? Just put this in your order notes. For other trim colours, mention it in your order notes or send us a custom enquiry.

11. Can I add charging sockets, a ScanGauge or a RedVision display?
  • Charging sockets: you can add a Narva 12V accessory socket and a dual USB socket (USB-A and USB-C available). These are normally fitted at the rear of the console, with USB on the driver's side and 12V on the passenger's side. They can also be housed inside the centre section, which is handy for powering a dash cam without visible cables. If you'd like to supply your own standard-size Narva sockets, we can cut the holes only.
  • ScanGauge II: fits on the 45° angled side facia.
  • ScanGauge III: too tall for the T-Shape facias. A K2C (Kimberley to Cape) mirror-mount bracket with a RAM mount is a good alternative.
  • REDARC RedVision: won't fit. It overhangs the console. Some customers ask for it to be custom mounted, but we don't recommend this because it doesn't fit within the console's dimensions. A K2C mirror-mount bracket is a great alternative.
  • Other units (TPMS monitors, Airbag Man, small displays): often possible as a custom provision. See Q3.

Wiring to your vehicle should be done by a qualified auto electrician.

12. Is it easy to install, and how far does it drop down?

Yes, it's easy to install. The T-Shape bolts straight into the factory mounting points (sun visor and grab-handle mounts, and the rear interior light mount), so there's no cutting or drilling. It's suitable for DIY, and comes with the hardware you need. Fitting guides are on our fitting instructions page. A second pair of hands helps: one person holds the console against the roof lining while the other starts the screws. Prefer us to fit it? We offer installation at our Kingsgrove warehouse in Sydney.

The console is slimline. It extends approximately 115mm down from the roof (measured at the interior light point), following the shape of the factory roof lining.

Roof sound deadening or insulation up to about 3mm thick is fine. Thicker material can push the roof lining down and make the mounting screws harder to engage. In most cases it can still be fitted with a second person compressing the console against the lining while the screws go in.

What is it made from?

Marine plywood and steel — no plastic. Upholstered in your choice of vinyl.

What are the Storage opening sizes on the T-Shape?

The approximate storage dimensions are:

  • Front storage openings — Depth: 140 mm; Opening width: 235 mm; Opening height: 70 mm at the front, tapering down to 40 mm.
  • Angled storage openings — Opening width: 290 mm.
  • Centre storage compartment — Opening width: 300 mm; Internal depth: 202 mm.

Please note that measurements are approximate and may vary slightly between vehicle models and console designs.
